Virtual Shaker Table Test with Ansys Mechanical

In almost all industries, multi-axis shaker tables are often used to study damage caused by motion including inertia loads or external forces in time domain or frequency domain. This process is highly expensive and time consuming requiring expensive protypes and fixture buildings.

Learn how:

• The use of simulation can speed up the process and reduce cost significantly.
• Structural excitation can be generated based on Mode based harmonic & transient analysis or full harmonic & transient analysis or multi body dynamics simulation.
• Workflows in Mechanical can perform full harmonic or transient simulation to generate physical stress/strain history or mode based harmonic or transient simulation to generate modal stresses and modal coordinates.

We will present & demonstrate virtual shaker table test within Ansys Mechanical & Ansys nCode DesignLife.
